Single phase 220V

0.4KW~4.0KW

Three phase 220V

0.4KW~75KW

Three phase 380V

0.75KW~160KW

Rated input voltage

Single-Phase 220V ± 20%
Three-Phase 220V ± 20%
Three-Phase 380V ± 20%

Rated input frequency

50~60Hz（±5%）

Rated output voltage

No greater than the input voltage

Rated output current

Frequency inverter rated output current

Overload capacity

G type machine: 150% rated current 1 minute, 180%
rated current 10 seconds
P type machine: 120% rated current for 1 minute,
150% rated current for 10 seconds

Control method

V / F control,vector control

Maximum frequency

500Hz

Frequency resolution

Numbers given: 0.1Hz
Simulation given: maximum frequency x 0.1%

Speed range

1:200（SVC）

Rotating speed

SVC: 5Hz above ± 5%

Torque compensation

Fixed torque lifting, arbitrary torque lifting

Acceleration and deceleration curves

Straight line, S curve

Acceleration/deceleration time

0.01S~600.00S

Automatic Voltage Regulation

When the grid voltage changes, it can automatically
keep the output voltage constant

Overcurrent, voltage stall

Automatic limit of current and voltage during operation to prevent frequent over-current voltage trip

DC braking

DC brake frequency: 0.10Hz~60.00Hz
Brake time; 0.00S~30.00S
Brake action current value; 0.00%~150.00%

External power source

10V/10mA
24V/150mA

Digital input

6-CH digital programmable input terminals

Digital output

1-CH programmable Y1 terminal output, 1-CH
programmable R1 relay output

Analog input

AI1:0~10 V voltage input
AI2:0~10 V / 0~20mA input

Analog output

0~10V / 0~20mA output

485 Communication

Support for standard Modbus communication protocols

LED display

5 digit digital display

Keypad

8 operation keys

Fault protection function

Input phase loss, output phase loss, overcurrent protection, overvoltage protection, undervoltage protection, overheat protection, overload protection, etc

Installation site

Indoor, no direct sunlight, no dust, corrosive gas, flammable gas, oil mist, water vapor, water dripping or salt, etc

Altitude

Below 1000 m

Ambient temperature

-10℃ ~+40℃
